Ламповый стереоусилитель мощности VTL S-200 Silver
под заказ
КРАТКОЕ ОПИСАНИЕ. Ламповый стереофонический усилитель мощности. Reference Series. Цвет: серебро
1 638 720 руб.
Технические характеристики


Vacuum Tube Complement 8 x 6550 or KT-88, 2 x 12AT7, 2 x 12BH7
Output power
20Hz – 20kHz <2.5% THD
Tetrode: 200W, Triode: 100W
into 5Ω load
Input sensitivity Variable between 700mV and 1.6V, depending upon DF setting
Input impedance 45kΩ
Load setting
Optimum load range 4Ω – 8Ω
S/N Ratio -110dB, 120 Hz
Power consumption Idle = 330W, Full power = 1000W
Primary mains fuse ratings 100/120V = 15A Ceramic Slo Blo, 220/240V = 8A Ceramic Slo Blo
Input fuse ratings 100/120V = 1A Ceramic Slo Blo, 220/240V = 1A Ceramic Slo Blo
Logic fuse 100/120V = 1A Ceramic Slo Blo, 220/240V = 1A Ceramic Slo Blo
B+ fuse ratings Plate Fuse – 1.0A fast acting 600V
Dimensions W x D x H 18.5 x 18 x 9 inches (47 x 45.7 x 23 cm)
Weight 105lbs (47.6Kg) unpacked, 120lbs (54Kg) packed
